19
LOADING PLATFORM AT BED HEIGHT
FIG. 19-1
PLATFORM
8. Load the platform at bed
height (FIG. 19-1) as fol-
lows. Push load out of the
vehicle to correct position
on the platform. Place all
loads as close as possible
to the inboard edge of
the platform with heaviest
part toward the truck body
as shown in FIG. 19-1.
If standing on platform
with the load, stand in the
footprint area shown and
comply with the WARNING
on previous page.
Pulling the load from vehicle to platform can result in a fall from
platform and serious injury. When unloading vehicle, always
push the load out on the platform.
WARNING
!
VEHICLE
BODY
9. Lower the platform to
ground level (FIG. 19-2).
Move load off the platform
(FIG. 19-2).
UNLOADING PLATFORM AT GROUND LEVEL
FIG. 19-2
PLATFORM
INBOARD
EDGE
OPERATION - Continued
