MAXPhotonics MA1 Series User Manual

Chapter 4
Specification
1 -Optics Characteristic Parameters
No. Characteristics Test conditions Min. Nom. Max. Unit
1 Operation mode
CW/Modulated
2 Polarization Random
3 Output 100% CW
The ambient
temperature
is 26℃
800
W
1200
1500
4
Power regulation
range
1% gradient 10 100 %
5 Central wavelength 100% CW 1080 nm
6
Electro-optical
efficiency
10-100%Linear fitting
27 %
7
Spectral bandwidth
(3dB)
100% CW 3 5 nm
8
Short-time power
stability
100% CW>1h 2 %
9 M2 100% CW 1.3
10
Laser switching ON
time
10%→90%Output 50 100 us
11
Laser switching OFF
time
90%→10%Output 50 100 us
12
Indicated red light
power
100% CW 300 1000 uW
13
Length of optical
fiber armored cable
MA1-35
4.35
m
MA1-45&MA1-65 5.6
14
Bending radius of
optical fiber armored
cable
200 mm
15 Output form QCS integrated with the tip
16
Continuous light
output time (S)
Light 120S, stop 6S
38
