RC12 Windlass
4. Insert emergency handle on shaft.
5. Make sure pawl is not sandwiched on top of chainwheel
6. Ensure that emergency handle pawl is engaged with
upper chainwheel. Replace clutch nut.
7. Rotate clockwise to pull in the line.
Ensure that self locking mechanism is engaged with bottom chainwheel before you
remove handle.
Above images are taken of the clockwise windlass.
