Maxxus Multipress 9.1 - Page 11

Assembly - Multipress
Step 8
11
11
36
11
36
As shown in the figure, unscrew the screw
by using the 4# L-type inner hexagon
wrench ,then assemble Rear barbell pole
assembly（No.11） and lock it well by
using 4# L-type inner hexagon wrench .
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
11
Rear barbell pole assembly
2
36 50 Spring clamp 2
