Assembly - Multipress
32
24
52
63
35 63
61
52 63
35 63
61
52
63 35
63 61
Step 20
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
24 Cross pulley U assembly 1 61
External hexagon anti-proof
screw：M10
3
32 Chest clamping wire rope 1 63
Flat washer ：
φ10
6
35 Pulley 3
52
External hexagon screw：M10*45
3
