Maxxus Multipress 9.1 - Step 26: Final Supports and Pulls

Maxxus Multipress 9.1
54 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
29
Assembly - Multipress
Step 26
49
49
49
49
45
45
43
43
41 42
60
60
60
60
60
40
39
39
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
39 Safety support 2 43 Single section pull 2
40 Hook leg foam assembly 1 45 Long chain 2
41 Double rod assembly-L 1 49 Gourd hook 4
42 Double rod assembly-R 1 60 T-shaped bolt 5
