Assembly - Multipress
Step 4
12
63
63
63 63
6350
50
50
63
50
50
50
7
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
12
Middle top connection assembly
1
50
External hexagon screw：M10*20
6
63
Flat washer ：
φ10
6
