33
Parts List – Multipress
No.
Product name
Diagram
Qty.
28
Rowing baffle assembly
1
29
Rear double pulley mounting
assembly
1
30
Barbell fixed wire
rope （L=2290mm）
1
31
Low draw wire
rope
（L=3705mm）
1
32
Chest clamping wire
rope （L=3195mm）
1
33
Flyer wire rope
（L=10510mm）
1
34 Back cushion 1
35 Pulley 7
36 50 Spring clamp 12
