24
Assembly - Multipress
A
B
C
D
31
49
46
49
48
51
47
61
Step 21
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
31 Low draw wire rope 1 49 Gourd hook 2
46 Short chain 1 51
External hexagon screw：
M10*30
1
47 Wire rope fixing U-shaped support 1 61
External hexagon anti-proof
screw：M10
1
48 Wire rope collision ball 1
