27
Assembly - Multipress
Step 24
27
54
54
63
63
63
63
61
61
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
27 The Olympic rod fixing frame 1 61
External hexagon anti-proof
screw：M10
2
54
External hexagon screw：M10*70
2 63
Flat washer ：φ10
4
