19
Assembly - Multipress
Step 16
61
63
63
55
25
Spare parts of installation step
No. Product name Qty. No. Product name Qty.
25 Swing U-shaped support assembly 1 61
External hexagon anti-proof
screw：M10
1
55
External hexagon screw：M10*75
1
63
Flat washer ：
φ10
2
