Maytag MAT23MN - FOR MAYTAG AUTHORIZED SERVICE PERSONNEL ONLY Tools & Parts; Alternate Parts & Accessories

7
TOOLS & PARTS
Tools & Parts Needed:
ALTERNATE PARTS & ACCESSORIES
If You Have: You Will Need:
Overhead sewer Standard 76 L (20 gallons)
990 mm (39") tall drain tub or utility
sink, sump pump, and connectors
(available from local plumbing
suppliers)
25 mm (1") standpipe 51 mm (2") diameter to 25 mm (1")
diameter Standpipe Adapter Part
Number 3363920,
Connector Kit Part Number 285835
Lint clogged drain Drain Protector Part Number
367031, Connector Kit Part Number
285835
Floor drain system Siphon Break Part Number 285320,
Connector Kit (x2) Part Number
285835, Extension Drain Hose Part
Number 285863
If You Have: You Will Need:
Water faucets beyond
reach of ll hoses
2 longer water ll hoses:
1.8 m (6 ft) 90° bend hose
Part Number 76314, 3.0 m (10 ft)
Part Number 350008
Inlet hoses are sold as a pair
in kit W10575888
Accessories
If You Have: You Will Need:
Washer Drip Trays
Part Number 8212526
Fabric Softener Dispenser Kit
Part Number 63594
Drain beyond the reach
of drain hose
1.2 m (4 ft) Drain Hose Extension
Part Number DRNEXT4
FOR MAYTAG AUTHORIZED SERVICE PERSONNEL ONLY
Your installation may require additional parts. To order, please contact the dealer from whom you purchased your washer or
an authorized service company.
Parts Supplied:
Inlet Hoses (2) Water Inlet Hose Washers (4)
Level Pliers Utility Knife
Flat-Blade Screwdriver
Optional tools:
Drain Hose with Clamp,
U-Form, and Cable Tie
Flashlight Bucket
9/16" Open-End Wrench
or Adjustable Wrench
