3-16
1. Remove two T-20 screws from the bottom
half of each hinge. These are self-tapping
screws.
2. Unlock the two locks at the front corners of
the cabinet.
3. Lift the top panel and slide it back.
4. Grasp the panel from the sides, lift and slide
the panel off the top of the washer.
NOTE: The top half of each hinge is riveted
to the top panel. If it is necessary to replace
a hinge, rivets would have to be drilled out.
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before
operating.
TOP PANEL REMOVAL
Two T-20
Screws
Rivets
To Next Page
