qFuel Gauge
The fuel gauge shows approximately how
much fuel is remaining in the tank when
the ignition is switched ON. We
recommend keeping the tank over 1/4 full.
Type A
Full
Empty
1/4 Full
Type B
Full
Empty
1/4 Full
If the low fuel warning light illuminates or
the fuel level is very low, refuel as soon as
possible.
Refer to Warning/Indicator Lights on page
4-33.
NOTE
l
After refuelling, it may require some
time for the indicator to stabilize. In
addition, the indicator may deviate
while driving on a slope or curve
since the fuel moves in the tank.
l
The display indicating a quarter or
less remaining fuel has more
segments to show the remaining fuel
level in greater detail.
l
The direction of the arrow ( )
indicates that the fuel-filler flap is on
the left side of the vehicle.
4-24
When Driving
Instrument Cluster and Display
