Warning/Indicator Lights
qType A
Warning/Indicator lights will appear in any of the highlighted areas
(Display example)
Displays as follows:
Master
warning
light
Indication in display and master warning light in instrument cluster are illuminated
at same time
This indicates a malfunct ion with the vehicle system. Check the message indicated in the
display and consult an expert repairer, we recommend an Authorised Mazda Repairer. For
details, refer to the explan ations for the warning/indicator lights, in the warning/indicator
lights section, which mat ch the symbol in the upper part of the display. If a message is not
indicated in the display, operate the INFO switch to display the “Warning” screen.
When Driving
Instrument Cluster and Display
4-33
