Distance Recognition Support System
(DRSS) display (Type A instrument
cluster)
í
Information regarding the Distance
Recognition Support Sy stem (DRSS) is
displayed.
Refer to Distance Recognition Support
System (DRSS) on page 4-147.
Warning (Display Indication) (Type A
instrument cluster)
A message is displayed to notify the user
of the system operation status and
malfunctions or abnormalities.
Check the indicated mess age.
When the master warning light is
illuminated in the instrument cluster,
message information is indicated in the
display to notify the user of the system
malfunctions.
l
Indication in display and master
warning light in instrument cluster
are illuminated at same time
This indicates a malfunct ion with the
vehicle system. Check the message
indicated in the display and consult an
expert repairer, we recommend an
Authorised Mazda Repairer. For
details, refer to the explan ations for the
warning/indicator lights, in the
warning/indicator lights section, which
match the symbol in the upper part of
the display. If a message is not
indicated in the display, operate the
INFO switch to display the “Warning”
screen.
l
Warning light matching symbol in
upper part of display is illuminated
The reason for a warning light being
illuminated in the display is explained
below the symbol. For details, refer to
the explanations for the warning/
indicator lights, in the war ning/
indicator lights section. Be aware that
there may be a malfunction with the
vehicle system.
l
Only message is indicated in the
display
This does not indicate a malfunction.
Check the indicated mess age.
4-32
When Driving
í
Some models.
Instrument Cluster and Display
