NOTE
l
The pretensioner system will activate
in a moderate or greater frontal or
near-frontal, or a severe side
collision. It will not activate in most
rollovers, rear impacts.
l
Some smoke (non-toxic gas) will be
released when the air bags and
pretensioners deploy. This does not
indicate a fire. This gas normally has
no effect on occupants, however,
those with sensitive skin may
experience light skin irritation. If
residue from the deployment of the
air bags or the front pretensioner
system gets on the skin or in the
eyes, wash it off as soon as possible.
Centre-Rear Position Seat
Belt
Before using the centre-rear lap/shoulder
belt make sure tongue (A) and anchor
buckle (B) are fastened.
(A)
(B)
qFastening the Seat Belt
1. Grasp the seat belt tongue (C).
2. Slowly pull out the lap/shoulder belt.
3. Insert the seat belt tongue (C) into the
seat belt buckle (D) until you hear a
click sound.
(A)
(B)
(C)
(D)
2-24
Essential Safety Equipment
Seat Belt Systems
