When “ 4WD system malfunction ” is
indicated
Contact an expert repairer, we recommend
an Authorised Mazda Repairer.
When “ 4WD system high-load” is
indicated
Park the vehicle in a safe place. After a
few moments, if the indication disappears,
you can resume driving. If the indi cation
does not disappear, contact an expert
repairer, we recommend an Authorised
Mazda Repairer.
Type B
This warning light stays on for a few
seconds when the ignition is switched
ON.
The warning light will illuminate or flash
under the following conditions:
l
Illuminates when there is an
abnormality with the 4WD system.
l
Illuminates if there is too much
difference in tyre radius between the
front and rear wheels.
l
Flashes when the differential oil
temperature is abnormally high.
l
Flashes when there is a continuous
large difference between front and rear
wheel rotation, such as when trying to
pull away from an icy surface or when
trying to remove the vehicle from mud,
sand or similar conditions.
When illuminated
If the 4WD warning light illuminates,
contact an expert repairer, we recommend
an Authorised Mazda Repairer.
When flashing
Park the vehicle in a safe place. After a
few moments, if the warning light stops
flashing, you can resume driving. If the
light does not stop flashing, contac t an
expert repairer, we recommend an
Authorised Mazda Repairer.
qAutomatic Transaxle Warning
Indication/Warning Light
í
Type B
This warning light stays on for a few
seconds when the ignition is switched
ON.
Type A/Type B
The light/indication illuminates when the
transaxle has a problem.
CAUTION
If the automatic transaxle warning light/
warning indication illuminates, the
transaxle has an electrical problem.
Continuing to drive your Mazda in this
condition could cau se damage to your
transaxle. Consult an expert repairer,
we recommend an Authorised Mazda
Repairer as soon as possible.
When Driving
Instrument Cluster and Display
4-51
í
Some models.
