Laser sensor radiation data
Maximum average power:45 mW
Pulse duration:33 ns
Wavelength:905 nm
Divergence angle (horizontal×vertical):28 degrees×12 degrees
NOTE
l
In the following cases, the laser sensor (front) cannot detect vehicles ahead correctly,
and each system may be unable to operate normally.
l
The windscreen is dirty.
l
Elongated luggage or cargo is loaded onto installed roof rails and covers the laser
sensor (front).
l
Exhaust gas from the vehicle in front, sand, snow, and water vapour rising from
manholes and grating, and water splashed into the air.
l
If there are recognizable cracks or damage caused by flying gravel or debris on the
windscreen, always have the windscreen replaced. Consult an Authorised Mazda
Repairer for replacement.
When Driving
i-ACTIVSENSE
4-203
