4. Disconnect the bulb from the socket.
Brake lights/Tail lights
Rear direction indicator lights
Tail lights (Liftgate side)
Reverse lights
5. Install the new bulb in the reverse order
of the removal procedure.
Rear fog light
í
1. Make sure the ignition is switched off
and the headlight switch is off.
2. Pull the centre of each plastic retainer
and remove the retainers and cover.
Removal
Installation
3. Turn the socket and bulb assembly
anticlockwise and remove it.
6-58
Maintenance and Care
í
Some models.
Owner Maintenance
