Check the tyre pressure label for tyre size and inflation press ure (page 6-45).
After adjusting the tyre pressure, initializat ion of the tyre pressure monitoring system is
necessary to make the system operates normally.
Refer to Tyre Pressure Monitoring System Initialization on page 4-214.
Standard tyre
Tyre size
Inflation pressure
Up to 3 persons ―Full load
225/65R17 102V
Front 230 kPa (2.3 bar, 33 psi) 260 kPa (2.6 bar, 38 psi)
Rear 230 kPa (2.3 bar, 33 psi) 280 kPa (2.8 bar, 41 psi)
225/55R19 99V
Front 250 kPa (2.5 bar, 36 psi) 260 kPa (2.6 bar, 38 psi)
Rear 250 kPa (2.5 bar, 36 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
Temporary spare tyre
í
Tyre size Inflation pressure
185/80R17 95M 250 kPa (2.5 bar, 36 psi)
Winter tyre
Tyre size
Inflation pressure
Up to 3 persons ―Full load
225/65R17
*1
M S
Front 230 kPa (2.3 bar, 33 psi) 260 kPa (2.6 bar, 38 psi)
Rear 250 kPa (2.5 bar, 36 psi) 300 kPa (3.0 bar, 44 psi)
225/55R19
*2
M S
Front 250 kPa (2.5 bar, 36 psi) 260 kPa (2.6 bar, 38 psi)
Rear 270 kPa (2.7 bar, 39 psi) 310 kPa (3.1 bar, 45 psi)
1 person's weight: About 75 kg
*1 Load index and Speed Symbol: 102Q/102S/102H/102V
*2 Load index and Speed Symbol: 99Q/99S/99H/99V
Wheel nut tightening torque
When installing a tyre, tighten the wheel nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
qFuses
Refer to Fuses on page 6-62.
qBrakes
If you require information regarding the wear limit specification for the brake disc plates
and the measurement method, please contact an expert repairer, we recommend an
Authorised Mazda Repairer. The information is made freely available.
Specifications
9-11
í
Some models.
