Mazda CX-7 2011 - Front Body Straight-Line Dimensions (1)[Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–4
FRONT BODY STRAIGHT-LINE DIMENSIONS (1)[DIMENSIONS]
id098010740600
.
End Of Sie
A
B
C
D
E
A'
B'
C'
D'
E'
mm
1,216
1,625
843
1,588
1,464
1,229
920
957
855
{in}
{47.87}
{63.98}
{33.19}
{62.52}
{57.64}
{48.39}
{37.68}
{36.22}
{33.66}
acxuub00000004
Fr
Fr
Fr
Fr
Fr
A B C D E
acxuub00000005
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A Roof seamless location -
B Front pillar projection location -
C Shroud side stay datum hole φ7 {0.28}
D Shroud side panel datum hole φ15 {0.59}
E
Front bumper bracket datum
hole
φ10 {0.39}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
