BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–12
APRON REINFORCEMENT (UPPER) REMOVAL[PANEL REPLACEMENT]
id098008800000
1. Drill the 1 location indicated by (A) from the bottom, as they cannot be seen from the outer side.
2. Remove the apron reinforcement (upper).
End Of Sie
APRON REINFORCEMENT (UPPER)
7
8
3
(A)1
acxuub00000082
