Mazda CX-7 2011 - Rear Body Straight-Line Dimensions (1)[Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–12
End Of Sie
BM: REAR BODY
REAR BODY STRAIGHT-LINE DIMENSIONS (1)[DIMENSIONS]
id098010746300
.
A
A'
B
C
D
B'
D'
C'
E
E'
F'
F
725
953
1,168
1,030
581
461
629
1,399
979
600
1,573
mm
1,242
304
1,431
{in}
{28.54}
{40.55}
{55.08}
{22.87}
{45.98}
{37.52}
{61.93}
{24.76}
{18.15}
{38.54}
{23.62}
{48.90}
{11.97}
{56.34}
acxuub00000016
Fr
Fr Fr Fr
Fr
Fr
Fr
A B C D E
F F
,
acxuub00000017
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A Liftgate hinge installation hole φ12 {0.47}
B Rear pillar outer datum hole φ10 {0.39}
C Corner plate datum slot
φ8 × 16
{0.31 × 0.63}
D Rear end panel square hole
8 × 6.1
{0.31 × 0.24}
E Rear end member square hole
28 × 8
{1.10 × 0.31}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
