BODY STRUCTURE [DIMENSIONS]
09-80D–10
ROOM STRAIGHT-LINE DIMENSIONS (2)[DIMENSIONS]
id098010743400
.
End Of Sie
A
B
H-H'
C
E
G
F
D
mm
1,150
931
729
1,438
1,408
1,101
1,564
{in}
{45.28}
{36.65}
{28.70}
{61.57}
{56.61}
{55.43}
{43.35}
acxuub00000012
Fr
Fr
Fr Fr
Fr
Fr
Fr
Fr
A B C D,D
,
D
,
D
E
F G H
acxuub00000013
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A Center pillar inner datum hole φ16 {0.63}
B Center pillar inner datum hole φ10 {0.39}
C Center pillar inner square hole
26 × 6
{1.02 × 0.24}
D,D’
Parking brake bracket datum
hole
φ10 {0.39}
E Rear pillar inner datum hole φ7 {0.28}
F Rear seat bracket datum hole φ5 {0.20}
G Rear pillar inner datum hole φ7 {0.28}
H Side frame outer datum hole φ12 {0.47}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
