Mazda CX-7 2011 - Wheel Apron Panel (Front) Removal[Panel Replacement]

BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–16
WHEEL APRON PANEL (FRONT) REMOVAL[PANEL REPLACEMENT]
id098008741100
1. Remove the wheel apron panel (front).
End Of Sie
5
11
12
5
WHEEL APRON PANEL FRONT (LH)
WHEEL APRON PANEL
FRONT (RH)
acxuub00000086
