Mazda CX-7 2011 - Front Body Straight-Line Dimensions (3)[Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–6
FRONT BODY STRAIGHT-LINE DIMENSIONS (3)[DIMENSIONS]
id098010740800
.
A
B
C
D
E
F
B'
C'
D'
E'
1,474
1,335
1,219
1,108
908
1,500
385
642
242
1,380
mm
{58.03}
{52.56}
{47.99}
{43.62}
{35.75}
{59.06}
{15.16}
{25.28}
{9.53}
{54.33}
{in}
acxuub00000008
A B
F
C D E
Fr
Fr
Fr
Fr
Fr
Fr
acxuub00000009
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A
Dash member upper datum
hole
φ8 {0.31}
B Hood hinge installation hole φ14 {0.55}
C
Apron reinforcement upper
datum hole
φ12 {0.47}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
