BODY STRUCTURE [PLASTIC BODY PARTS]
09-80E–7
09-80E
7. Sand the area with #180—240 sandpaper.
Note
• If excessive force is applied to the area when sanding, the surface will be damaged.
• If fuzz remains around the repaired area, melt it with a heat gun.
8. Degrease the painted surface.
9. Mix the primer and the hardener at a ratio of one to one. Apply the primer to the repaired area and the surface
of the bumper with a brush or spray.
Use the primer within 16 hours after it is mixed.
Note
• Polypropylene primer will dissolve even after drying if it is wiped with solvent. Use only water to clean
around the primer.
10. Allow the part to dry.
am8rrb00000062
11
polypropylene primer
Primer hardener
am8rrb00000060
