ENGINE
B–45
B
2. Install the cylinder head cover bolts in the order
as shown.
Crankshaft Pulley Lock Bolt Aassembly Note
1. Install the SST to the camshaft as shown.
Europe
Except Europe
2. Install the M6 x 1.0 bolt in by hand.
3. Turn the crankshaft clockwise so that the
crankshaft is in the No.1 cylinder TDC position.
Bolt No. Tigtining torque N·m {kgf·m, ft·lbf}
1—18 8.0—11.5 N·m
{81.6—117.2 kgf·cm, 70.9—101.7 in·lbf}
19—22 40—55 {4.1—5.6, 29.7—40.5}
AME2224E334
AME2224E329
AME2224E328
AME2224E009
