BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–32
FRONT FRAME COMPONENT REMOVAL[PANEL REPLACEMENT]
id098008616400
1. Drill the 2 location indicated by (A) from the interior, as they cannot be seen from the outer side.
2. Remove the front frame component.
6
(A)2
DRIVER'S SIDE:7
PASSENGER'S SIDE:8
FRONT FRAME COMPONENT
D5U0980B062
