GENERAL INFORMATION
00-00–6
Body Dimensions (Straight-line Dimensions)
• Straight-line dimensions are the actual dimensions between two standard points.
817
FRONT FENDER INSTALLATION NUT
STRAIGHT-LINE DIMENSIONS
{32.17}
DPE2010B011
3426-1U-06F(00-00).fm 6 ページ ２００６年６月２０日　火曜日　午後３時３６分
