Mazda mx-5 2007 - Rear Fender Panel (Lower) Installation[Panel Replacement]

BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–52
REAR FENDER PANEL (LOWER) INSTALLATION[PANEL REPLACEMENT]
id098008614400
1. When installing new parts, measure and adjust the body as necessary to conform with standard dimensions.
2. Drill holes for plug welds before installing new parts.
3. After temporarily installing new parts, make sure the related parts fit properly.
End Of Sie
5
4
3
REAR FENDER PANEL (LOWER)
D5U0980B084
