BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–48
5. Install the front pillar reinforcement.
6. Install the cowl side panel.
FRONT PILLAR REINFORCEMENT
2
2
D5U0980B079
3426-1U-06F(09-80B).fm 48 ページ ２００６年６月２０日　火曜日　午後７時３２分
