MBM 206M - Machine Parts Identification

1
2
3
4
5
6
7
8
9
(3) Description of Parts
Number Name Number Name
Roller cover 10 Table 1
Left side cover 11 Control panel
Paper feed roller 12 Paper feed table
Paper guide 13 Table 2
Auxiliary feed table
14
Right side cover
Paper discharge roller 15 Paper feed table lever
Paper stacking table
Stopper plate
16
17
Power source switch
Inlet
Fold position adjustment knob 18 Circuit breaker
6
