MBM 306A - Component Identification

1
2
3
4
5
6
7
8
9
10
(3) Part Names
Number Name Number Name
Roller cover
Left side cover
11
12
Paper feed table
Table 2
Paper feed roller
Paper guide
13
14
Right side cover
Paper feed table lever (306A only)
Auxiliary feed table 15 Table 1 socket
Paper eject roller 16 Table 2 socket
Paper ejection table 17 Power switch
Stopper fine adjustment knob 18 Inlet
Table 1 19 Circuit breaker
Control panel
-6-
