9
2. Volume
The MC 601 is equipped with a special potentiometer made for audio use. Press the right button for volume up
and the left button for volume down.
3. Input selectors
With the input selectors you can select one of the various sources connected to the preamplifier. The processor
input enables the connection of an extern sourround-decoder. Choosing this input will engage a signal to the
connected amplifier (Bypass). This gives the possibility to switch between audio (music replay) and video (DVD).
Plugged in Phono MM, Phono MC or CD-direct modules can be selected by using the option button.
Input selector Source
Balanced Balanced XLR input
CD 1 RCA, CD input, 10 kOhm
CD 2 RCA, CD input, 10 kOhm
Tuner RCA high level input, 50 kOhm
Aux RCA high level input, 50 kOhm
Option optional input for Phono MM, Phono MC
Processor Bypass for surround-processor, 10 kOhm
4. On / Standby / Off
The “on button“ on the front panel puts the preamp into standby and turns it back to “on” (this function can also
be accomplished by remote control). The blue LED on the display lights when the amplifier is in stand by mode.
To turn off the preamplifier completely (the unit is no longer connected to the mains and therefore does not
consume current), disconnect the power cord from the mains socket. This is recommended, when the pream-
plifier is not in use for a longer period of time.
5. Display
The display indicates the volume level as well as the input that is currently in use.
19,2
balanced
standby
disp.off
function LED‘sinput indicator
volume
mc 601
