17
3. Pre / Integrated amplifier controls
The PRE button (1) activates the preamplifier or integrated amplifier. The other preamplifier related controls are
as follows:
Please note: The power amplifier volume can be controlled at any time.
G. Troubleshooting
1. Replacement of the fuses
The fuse holder is integrated in the main socket. It is located on the rear side of the unit. When replacing the
fuses, remember to:
• Pull the plug from the wall outlet first! If you do not, you will risk damage to the unit as well as to your life.
• Pull out the fuse holder, which is installed above or below the power connector on the back panel.
• The fuse holder contains 2 fuses (0.5 AT for 230 VA, and 1.0 AT for 110 VA). The left fuse is the active one, the
right one is in reserve. Exchange accordingly and put the fuse holder back in an re-plug the unit to the wall.
2. Change of main voltage
A change of the main voltage can only be done by an authorized dealer. This procedure is not a warranty ser-
vice. A change of the main voltage always requires a change of the fuses.
Warning: If opened by anybody other than qualified MC dealers, MC will not take responsibility for any damage
to machinery or life. And any warranty claims will bevoid!
Button Function
2: volume up
3: volume down
4: select input up
5: select input down
6: output group 1 on / off
7: output group 2 on / off
8: step through brightness levels of the display
9: Mute: turns sound on and off
10: switch to standby mode
2
4
3
6
1 2 3
4 5 6
7 8 9
0
1
5
OUT
PRE
REPEAT
MUTE TIME SHUFFLE STANDBY
DISP OFF
ERR LEV
A/B PROG
TUNER D/ACD
8
9
10
7
Remote Control
