MC 501 - MC 701 Integrated Amplifier

20
3. mc 701 Integrated Amplifier
Pre section
Inputs 6 inputs
XLR, CD (2x)
high level (2x)
processor (1x)
Option (1x)
Outputs Fixed out
Frequency Range DC - 400 kHz
Output level 1 Veff - 10 Veff max.
Output Impedance 100 Ohm
Noise Distortion <0.001%
Input Sensitivity 315 mW
Signal to Noise 101 dB, 1V / 25 Ohm
CD 107 dB, 1V / 25 Ohm
Input Impedance
High Level 50 kOhm, bypass 10 kOhm
CD 10 kOhm
Power section
Rated Power 120 W (8 Ohm), 185 W (4 Ohm)
Output Voltage max. 35 V
Output current max. 20 A
Input Sensitivity 1.5 V, 185 W, 4 Ohm
Channel Separation 90 dB
S/N Ratio
unweighted 111 dB
A-weighted 115 dB
Frequency Response DC - 135 kHz / -3 dB
Distortion THD + N <0.006%, 4 Ohm, 1 kHz, 50 W
Damping Factor 300 (4 Ohm)
Power Consumption
Sleep mode 4 VA
Idle mode 120 VA
Maximum 450 VA
Line Voltage (factory setting) 230 / 115 Vac, 50 / 60 Hz
Weight 17 kg, 37 lbs
Dimensions (W x H x D) 450 x 142 x 410 mm
18 x 5.7 x 16 inch
Specifications
