21
4. mc 801 Power Amplifier
Peak Pulse Power 500 W
Rated Power
8 Ohm 2 x 120 W
4 Ohm 2 x 185 W
Output Voltage max. 35 V peak
Output Current max. 20 A peak
Input Impedance
RCA 10 kOhm
XLR 10 kOhm
Input Sensitivity 1.5 V, 185 W 4 Ohm
S/N Ratio
unweighted 111 dB
A-weighted 115 dB
Frequency Response (Mono/Stereo) DC - 130 kHz
Distortion <0.006%, 4 Ohm, 1 kHz, 50 W
Damping Factor 300 (4 Ohm)
Power Consumption
Sleep mode 4 VA
Idle mode 47 VA
Maximum 450 VA
Line Voltage (factory setting) 230 / 115 Vac, 50 / 60 Hz
Weight 15 kg, 32 lbs
Dimensions (W x H x D) 450 x 142 x 410 mm
18 x 5.7 x 16 inch
Design and specifications are subject to change without notice
Specifications
