MC 501 - MC 601 Preamplifier

19
2. mc 601 Preamplifier
Inputs 6 + 1 inputs
XLR, CD (2x)
high level (2x)
processor (1x)
Option (1x)
Outputs 3 outputs
RCA (2x)
Balanced (1x)
Frequency Range
CD DC - 600 kHz
High level DC - 600 kHz
Output Level 1 Veff - 10 Veff max.
Output Impedance 100 Ohm
Noise Distortion (1 kHz, 2V) <0.0007%
Input Sensitivity (High level) 315 mV
Signal to Noise
CD 98 / 101 dB, 1V / 25 Ohm
High Level 105 / 108 dB, 1V / 25 Ohm
Maximum loading level 10 Veff
Input Impedance
CD 10 kOhm
High level 50 kOhm
Processor 10 kOhm
Channel Separation (High level) 100 dB
Power Consumption 20 VA max.
Line Voltage (factory setting) 230 / 115 Vac, 50 / 60 Hz
Weight 11 kg, 24 lbs
Dimensions (W x H x D) 450 x 120 x 410 mm
18 x 4.7 x 16 inch
Specifications
