9.0 SPECIFICATIONS
30124-60 Rev. 1.2 | 16DEC2019
Page 42
SPECIFICATIONS
ProComm
Power Source
AC 100-240 VAC / 45-66 Hz (10 W)
Note: AC or DC must be specied at time of
ordering.
DC 10-35 VDC (10 W)
Standard Outputs
Dual 4-20mA Outputs: Galvanically isolated and fully programmable for zero and full scale
(0-21mA rangeability)
Two separate digital programmable outputs: open collector transistor usable for pulse,
frequency, or alarm settings.
• Volumetric Pulse
• Flow Rate (Frequency)
• Hardware Alarm
• High/Low Flow Alarms
• Empty Pipe
• Directional Indication
• Range Indication
• Maximum switching voltage:
40 VDC
• Maximum switching current:
100mA
• Maximum switching
frequency: 1250 Hz
• Insulation from other
secondary circuits: 500V
Optional Outputs
• Modbus
• HART
• Smart Output
™
(Sensus, Itron
6, Itron 9)
• Datalogger
• Built-in verification
Galvanic Isolation
All inputs / outputs are galvanically isolated from power supply up to 500 V
Engineering Units
• Cubic Meter
• Cubic Centimeter
• Milliliter
• Liter
• Cubic Decimeter
• Decaliter
• Hectoliter
• Cubic Inches
• US Gallons
• Imperial Gallons
• Cubic Feet
• Kilo Cubic Feet
• Standard Barrel
• Oil Barrel
• US Kilogallon
• Ten Thousands of Gallons
• Imperial Kilogallon
• Acre Feet
• Megagallon
• Imperial Megagallon
• Hundred Cubic Feet
• Megaliters
Conductivity
Minimum conductivity of 5µS/cm
Electrical Connections
Connection options • Compression gland seals for 0.24” to 0.47” diameter round cable
• Conduit option: 1/2” NPT threaded connections
Sensor Cable Lengths
Standard 25’ McCrometer supplied submersible cable with each remote mount unit.
Optional Up to 500 feet, or 25 feet max for battery powered.
Quick Connect * Available in standard cable lengths: 25’, 50’, 75’, 100’, 125’, 150’, 175, 200’, and 500’. Custom cable
lengths at additional cost.
IP Rating
IP67 Die cast aluminum converter (only when connected using compression gland seals)
* Not available with SPI Mag
