McCrometer ProComm HL - Keypad and Display

30124-60 Rev. 1.2 | 16DEC2019
Page 43
SPECIFICATIONS
ProComm
Certications and Approvals
Standard Model • ISO 9001:2015 certied quality management system
• CE
• Certied by MET to UL 61010-1
HL Model • ISO 9001:2015 certied quality management system
• CE
• Certied by MET to UL 61010-1 and MET C22.2 No. 61010-1-04
• Class I, Division 2, Groups A-D, T5
• Class I, Zone 2 IIC T5
i
IMPORTANT:
Electrical safety certications above do not apply to model 282L Single Point Inser-
tion (SPI Mag) Electromagnetic Flow Meter.
System Options
• Hastelloy® electrodes*
• DC power
• Additional sensor cable up to 475’ (500’ max for FPI Mag)
• Extension to hardware clearance
• Annual verication / calibration
• Sensor insertion tool*
• Stainless steel ID tag
Temperature Range
Operating and
storage
-20° to 60° C (-4° to 140° F)
Converter Dimensions
Remote mount* • Height: 7.3” (18.5 cm)
• Width: 8.5” (21.6 cm)
• Depth: 4.3” (10.9 cm)
Meter mount • Height: 6.9” (17.5 cm)
• Width: 7.2” (18.25 cm)
• Depth: 6.2” (15.7 cm)
Keypad and Display
Can be used to access and change set-up parameters using six membrane keys and an LCD
display
* Not available with SPI Mag
Note regarding cable length: McCrometer recommends minimizing cable length. Electromagnetic ow meters may have
unfavorable signal strength to noise ratio in electrically noisy environments. Longer lengths of cable increase the likelihood
of interference. In those cases where the meter’s signal must be transmitted a long distance, or where the environment
may be particularly noisy, we suggest using the converter’s analog output(s). That allows locating the converter as close as
possible to the metering location.
