McDonald's C835 - Page 35

33
14. Dip the Kay Grill Cleaning Pad Holder into
the grill cleaner. (See Figure 73.)
Figure 73
IMPORTANT: DO NOT scrub while applying
the grill cleaner in the following s teps:
15. Apply McD Hi-Temp Grill Cleaner
(HTGC) to the front side of the platens,
starting from the right platen to the left
platen. (See Figure 74.)
Figure 74
DO NOT USE METAL SCRAPERS,
ABRASIVE PADS, SCREENS OR WIRE
BRUSHES ON THE UPPER PLATENS.
DAMAGE TO COMPONENTS MAY RESULT.
16. Apply the grill cleaner to the platen
surfaces, starting from the right platen to
the left platen. (See Figure 75.)
Figure 75
17. Apply the grill cleaner to the back side of
the platens, from the right platen to the
left platen. (See Figure 76.)
Figure 76
18. Apply the grill cleaner to the outer edges
of the right and left platens.
(See Figure 77.)
Figure 77
