29
Setup, con’t
Trigger Selection
The Trigger A and B Power Control Outputs on the C1000
Controller are reassignable from their default setting of go-
ing On and Off with the C1000C, to activating only when a
given Input or Inputs are selected. To change either Trigger
A or B from the default setting perform the following steps:
Note: Power Control Cables coming from the components to
be controlled need to be connected to the correct
Trigger Jack on the Rear Panel of the C1000C to
function.
1. Press the SETUP Push-button twice to access the Setup
Preamp Mode unless the C1000C is already in the
Setup Preamp Mode.
2. Rotate the BALANCE (Menu) Control until the Alpha-
numeric Display indicates “TRIG TUN --” . Refer to
figure 36.
3. Rotate the RECORD (Select) Control until the desired
Figure 36
Figure 35
Figure 34
5. If necessary, rotate the RECORD (Select) Control until
two zeros appears in the center of the Front Panel Al-
phanumeric Display, “TRIM 0.0 TUN”.
6. Rotate the LISTEN (Select) Control until the word CD
appears on the right side of the Front Panel Alphanu-
meric Display, “TRIM 0.0 CD”. Refer to figure 34.
7. Rotate the RECORD (Select) Control until the Volume
Level of the CD Input is the same as the Tuner Volume
Level. Figure 35 indicates a 3.0dB decrease in the CD
Level.
8. Rotate the LISTEN (Select) Control until the next de-
sired Input Source Name is displayed.
9. Repeat steps 6, 7 and 8 until all the Inputs with sources
connected to the C1000 have the same relative volume
levels when switching between them.
10. If no other adjustments are to be made at this time,
press the SETUP Push-button to exit the Setup Preamp
Mode or proceed to the next desired Setup Preamp
Mode for adjustment.
Input Title to be changed appears in the Display, e.g.
“TRIG DVD --” .
4. Rotate the LISTEN (Select) Control until the desired
Trigger A or B (in this example the DVD Input will ac-
tivate the Trigger A Jack) appears in the Display, e.g.
“TRIG DVD A”. Refer to figure 37.
Note: Additional Inputs may also be assigned in the
same manner to also activate Trigger A.
5. If no other adjustments are to be made at this time,
press the SETUP Push-button to exit the Setup Preamp
Mode or proceed to the next desired Setup Preamp
Mode for adjustment.
Figure 37
Accessory Control
When the Trigger A or B Power Control Outputs on the
C1000 Controller are used, one of the Triggers may be as-
signed to switched On or Off by using the ACCessory Push-
button on the supplied HR54 Remote Control. To select ei-
ther Trigger A or B for remote operation, perform the fol-
lowing steps:
1. Press the SETUP Push-button twice to access the Setup
Preamp Mode unless the C1000C is already in the
Setup Preamp Mode.
2. Rotate the BALANCE (Menu) Control until the Alpha-
numeric Display indicates “ACC CONTROL --”.
Refer to figure 38.
3. Rotate the LISTEN (Select) Control until the desired
Trigger A or B appears in the Display, e.g. “ACC
CONTROL A”. Refer to figure 39.
Note: Devices connected to the Trigger (A or B) Jacks
will be effected when Trigger (A or B) in SETUP is
changed.
4. If no other adjustments are to be made at this time,
press the SETUP Push-button to exit the Setup Preamp
Mode or proceed to the next desired Setup Preamp
Mode for adjustment.
Figure 38
Figure 39
