Specifications C1000 Preamplifier, C1000 Tube Preamplifier and C1000 Controller
Frequency Response
+0, -0.5dB from 10Hz to 40,000Hz
Total Harmonic Distortion
0.002% from 20Hz to 20,000Hz
Signal To Noise Ratio
High Level, 100dB
Phono, 88dB
Maximum Voltage Output
12V RMS Unbalanced, 25V RMS Balanced
Output Impedance
220 ohms
Sensitivity
High Level, 450mV for 2.5V rated output
Phono MM, 4.5mV for 2.5V rated output
Phono MC, 0.45mV for 2.5V rated output
Input Impedance
High Level, 22K ohms
Phono MM, 47K ohms; 50 to 750pF, in 50pF steps
Phono MC: 25, 50, 100, 200, 400 or 1,000 ohms;
100pF
Maximum Input Signal
High Level, 5V Unbalanced, 10V Balanced
Phono MM, 50mV
Phono MC, 5mV
Specifications C1000 Preamplifier Specifications C1000 Tube Preamplifier Specifications C1000 Controller General Specifications
Power Requirements
100 Volts, 50/60Hz at 120 watts
110 Volts, 50/60Hz at 120 watts
120 Volts, 50/60Hz at 120 watts
220 Volts, 50/60Hz at 120 watts
230 Volts, 50/60Hz at 120 watts
240 Volts, 50/60Hz at 120 watts
Note: Refer to the rear panel of the C1000 Controller
for the correct voltage.
Frequency Response
+0, -0.5dB from 10Hz to 20,000Hz
Total Harmonic Distortion
0.08% from 20Hz to 20,000Hz
Signal To Noise Ratio
High Level, 93dB
Phono, 80dB
Maximum Voltage Output
8V RMS Unbalanced, 16V RMS Balanced
Output Impedance
220 ohms
Sensitivity
High Level, 450mV for 2.5V rated output
Phono MM, 4.5mV for 2.5V rated output
Phono MC, 0.45mV for 2.5V rated output
Input Impedance
High Level, 22K ohms
Phono MM, 47K ohms; 50 to 750pF, in 50pF steps
Phono MC: 25, 50, 100, 200, 400 or 1,000 ohms;
100pF
Maximum Input Signal
High Level, 5V Unbalanced, 10V Balanced
Phono MM, 50mV
Phono MC, 5mV
Tube Compliment
Phono Circuitry:
4 - 12AX7A
High Level Circuitry:
4 - 12AX7A
Overall Dimensions
C1000C:
Width is 17-1/2 inches (44.45cm)
Height is 6 inches (15.24cm) including feet
Depth is 24 inches (61.0cm) including the Front
Panel, Knobs and Interconnect Cables
1
C1000P:
Width is 17-1/2 inches (44.45cm)
Height is 6 inches (15.24cm) including feet
Depth is 24 inches (61.0cm) including the Front
Panel and Interconnect Cables
1
C1000T:
Width is 17-1/2 inches (44.45cm)
Height is 6 inches (15.24cm) including feet
Depth is 24 inches (61.0cm) including the Front
Panel and Interconnect Cables
1
Weight
C1000C - 39.0 pounds (17.7 kg) net
61.4 pounds (27.9 kg) in shipping carton
C1000P - 33.0 pounds (15.0 kg) net
53.6 pounds (24.3 kg) in shipping carton
C1000T - 34.0 pounds (15.4 kg) net
54.6 pounds (24.8 kg) in shipping carton
1
Interconnect Cables are supplied with the C1000
Preamplifier and C1000 Tube Preamplifier. They
are used to connect Preamplifier(s) to the C1000
Controller.
