23
Setup, con’t
Remote Control Codes
The Remote Control included with the C1100 utilizes
the NORMAL McIntosh Control Codes. The Second
Set of Control Codes the C1100 will respond to is
referred to as the ALTERNATE Codes. The Alternate
Codes are used when the C1100 is used in the same
location as another McIntosh Preamplifier and/or A/V
Processor. This will prevent the Remote Control from
affecting the operation of both units at the same time.
To activate the Remote Control ALTERNATE Codes
perform the following steps:
1. Press the SETUP Push-button to enter the SETUP
MODE. Refer to figure 2, on page 18.
2. Rotate the TRIM Control until “SETUP: IR
Codes, Normal” appears on the Information
Display. Refer to figure 42.
3. Rotate the ADJUST Control to select the Alter-
nate Codes. Refer to figure 43.
4. It is now necessary to change the HR085 Remote
Control over to the Alternate Codes. Information
on the HR085 Remote Control is available for
download from the McIntosh Web Site:
http://www.mcintoshlabs.com/us/Products/pages/
ProductDetails.aspx?CatId=preamplifiers&Produ
ctId= C110 0
5. Exit the SETUP Mode by pressing the SETUP
Push-button.
Figure 42
SETUP: IR Codes
Normal
Figure 43
SETUP: IR Codes
Alternate
Power Mode
The C1100 incorporates an Auto Off Feature, which
automatically places the preamplifier into the Power
Saving Standby/Off Mode. This occurs approximately
30 minutes after there has been an absence of audio
input or user activity (includes changes to any of the
Operation Functions such as source selection, volume
adjustment, etc). If it is desirable to disable the Auto
Off Feature perform the following steps:
1. Press the SETUP Push-button to enter the SETUP
MODE. Refer to figure 2, on page 18.
2. Rotate the TRIM Control until “SETUP: Auto
Off, Enabled” appears on the Information Display.
Refer to figure 46.
3. Rotate the ADJUST Control to select Disabled.
Refer to figure 47.
4. Exit the SETUP Mode by pressing the SETUP
Push-button.
Figure 46
SETUP: Auto-Off
Enabled
Figure 47
SETUP: Auto Off
Disabled
IR Sensor
The C1100 Front Panel Sensor, which receives the sig-
nals from the HR085 Remote Control, can be switched
off to prevent interference when an external IR Sensor
is connected. To de-activate the Front Panel IR Sensor
perform the following steps:
1. Press the SETUP Push-button to enter the SETUP
MODE. Refer to figure 2, on page 18.
2. Rotate the TRIM Control until “SETUP: Front
IR, Enabled” appears on the Information Dis-
play. Refer to figure 44.
3. Rotate the VOLUME (ADJUST) Control to select
Disabled. Refer to figure 45.
4. Exit the SETUP Mode by pressing the SETUP
Push-button.
Figure 44
SETUP: Front IR
Enabled
Figure 45
SETUP: Front IR
Disabled
