McIntosh C1100 User Manual

15
How to use the HR085 Remote Control
How to use the Remote Control
The supplied C1100 Remote Control (HR085) is ca-
pable of directly controlling the functions of contem-
porary McIntosh Source Components connected to the
C1100 via the Data Ports.
Notes: 1. If at any time the C1100 seems unresponsive
to HR085 Remote Control Commands, press
the DEVICE Push-button to select
first.
2. For additional information on using the
HR085 Remote Control with the McIntosh
Model, please refer to “How to Operate”
starting on page 26.
3. For additional information on assigning the
Data Ports, refer to “How to Setup” on page
18.
Trim
Press the TRIM Push-button until the desired Trim
function (Balance, Trim Level, etc.) appears on the
C1100 Front Panel Display, then press the LEVEL Up
or Down Push-button to adjust the Trim setting.
Note: Press the TRIM Push-button to recall the last Trim
function selected. For additional information on
using the Trim Functions refer to “How to Oper-
ate” page 26.
Output Selection
Press the BLUE (Setup) Push‑button followed by
the AM (Output 1) or FM (Output 2) Push‑button, to
control the Rear Panel Audio OUTPUTS 1, 2 (ON or
OFF) and Power Control TRIG 1 / TRIG 2.
Note: For additional information on assigning the Out-
puts (1 and 2) and Power Control Triggers (1 and
2) refer to page 21.

McIntosh C1100 Specifications

General

Type	Preamplifier
Total Harmonic Distortion	0.005%
Frequency Response	20Hz to 20kHz +0, -0.5dB
Input Impedance	44K ohms
Output Impedance	200 ohms
Dimensions	Each chassis: 17-1/2" (44.45cm) width x 6" (15.24cm) height (including feet) x 18" (45.72cm) depth (including front panel and cables)
Rated Output Voltage	2.5V RMS
Phono Inputs	2 (MM/MC)
Balanced Outputs	2
Unbalanced Outputs	2
Maximum Voltage Gain	15dB
Gain	60dB (MC Phono); 40dB (MM Phono)
Inputs	High Level, Phono
Outputs	Balanced, Unbalanced
