3. Rotate the TRIM Control to select the next Setup
Mode Menu item, “SETUP: BAL 1, On / Re-
name.” Refer to figure 3. Continue to rotate the
INPUT CONTROL to view the other SETUP
Mode Options.
4. To exit from the SETUP Mode, press the SETUP
Push-button and the Front Panel Display will re-
vert back to its normal display. Refer to figure 1.
Your McIntosh C1100 has been factory configured for
default operating settings that will allow immediate
enjoyment of superb audio without the need for fur-
ther adjustments. If you wish to make changes to the
factory default settings, a Setup Feature is provided to
customize the operating settings using the Front Panel
Information Display. Refer to the C1100C Front Panel
Illustration on page 16 while performing the following
steps.
Note: If the C1100 is currently On, proceed to step 2.
1. Press the STANDBY/ON Push-button on the Front
Panel or press the (Power ON) Push‑button on
the Remote Control to switch On the C1100. The
C1100 will go through a TUBE WARMUP (15
seconds) with the Tubes in the C1100T glowing an
amber color and a brief startup initialization with
the Front Panel Information Display indicating the
last used source and volume setting. The illumina-
tion of the Tubes will now glow a green color; this
is followed by the volume setting indication start-
ing at zero, then increasing to the last used volume
setting. Refer to figure 1.
2. Press the SETUP Push-button, rotate TRIM
(MENU) Control until the Front Panel Informa-
tion Display indicates “C1100, V_.__ - S/N:
AEE____” (or higher Firmware version). Refer to
figure 2.
How to Operate the Setup Mode
The Default Settings Chart below indicates the Func-
tion Name, Default Setting and the Page Number for
additional information.
Default Settings
Firmware Version
Default Settings
Function Name Setting Page No.
C110 0 V_._ _ - _._ 18
INPUTS On / Rename 18
OUTPUTS (1 & 2) Switched 20
HEADPHONES Main = Unmuted 20
TRIGGER 1 Output 1 21
TRIGGER 2 Output 2 21
TRIGGERS (3 thru 4) Main 21
DATA PORTS
(1 thru 8)
All Data 22
PASST H RU OFF 22
RS232 (Rate) 115200 Baud 22
Remote Control
(IR Codes)
Normal
23
IR Sensor Enabled 23
Power Mode Enabled 24
Setup
Figure 2
C1100 V1.00
Figure 1
INPUT: BAL 1
15%
The C1100 provides the ability to switch unused
INPUTS Off (or back On if they have been previously
switched Off). The default INPUT Names can be
changed to match the name of the component con-
nected to it or any other custom name desired (within
10 Characters).
INPUT SWITCHED ON/OFF:
In the following example, the UNBAL 4 Input will be
switched Off.
Notes: 1. When an INPUT is swiched Off, its name will
no longer appear on the Front Panel Informa-
tion Display when using the INPUT Control
(Front Panel or Remote Control).
1. Press the SETUP Push-button to enter the SETUP
MODE. Refer to figure 2.
2. Rotate the TRIM Control until “SETUP: _____,
On / Rename” appears on the Information Display.
Refer to figure 3.
3. Then rotate the INPUT Control to select the UN-
BAL 4 Input. Refer to figure 4.
Input Settings
Figure 3
SETUP: BAL 1
On / Rename
The C1100 functionality is controlled by internal
software that is know as Firmware. The Version of the
Firmware in the C1100 can be identified at any time
by utilizing the Setup Mode.
1. Press the SETUP Push-button to enter Setup
Mode.
2. Referring to the Front Panel Information Display-
the number after the character “V” is the Firm-
ware number. Refer to figure 2.
3. To exit the Setup Mode, press the SETUP Push-
button.
