McIntosh C2600 Service Manual

C2600
REAR PANEL
3
POWER CONTROL
MAIN
TRIG 1
TRIG 3
PASSTHRU
TRIG 2
TRIG 4
120V 50/60Hz
50 WATTS
IR IN
RS232
EXTERNAL CONTROL
OPTICAL
1
COAXIAL
1
2
3
2
DIGITAL AUDIO INPUTS
MCT
USB
DATA PORTS
5
3
1
6
4
2
MC
GND
L
R
1R
BAL R
MAIN OUTPUT
BAL L BAL R BAL L
L
R
OUTPUT 1
BAL R BAL L
L
R
OUTPUT 2
SERIAL
NUMBER
1L 2R 2L 3R 3L
L
R
FIXED
OUTPUT
BALANCED INPUTS
1423
MM
L
R
UNBALANCED INPUTS PHONO INPUTS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
UNBAL UNBAL UNBAL
McINTOSH LABORATORY, INC. BINGHAMTON, NY
HANDCRAFTED IN USA WITH US AND IMPORTED PARTS
C 2600 T UBE PREAMPLIFIER
ATTENTION: RISQUEDECHOC ELECTRIQUE-NE PASOUVRIR

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
