McIntosh C2600 Service Manual

C2600
PARTS LIST
2
61
Ref. No. Description Part No.
C1 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C2 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C3 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C4 CAP ELECT 1000UF 25V 066513
C5 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C6 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C7 CAP MPF 0.047UF 5% 63VDC 064320
C8 CAP MPF 0.047UF 5% 63VDC 064320
C9 CAP ELECT 6800UF 25V 20% 066622
C10 CAP ELECT 6800UF 25V 20% 066622
C11 CAP ELECT 3300UF 35V 066509
C12 CAP ELECT 3300UF 35V 066509
C13 CAP ELECT 3300UF 35V 066509
C14 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C15 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C16 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C17 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C18 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C19 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C20 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C21 CAP 100pF 200V 5% SMD0805 061390
C22 CAP 100pF 200V 5% SMD0805 061390
C23 CAP 100pF 200V 5% SMD0805 061390
C24 CAP 100pF 200V 5% SMD0805 061390
C25 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C26 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C27 CAP ELECT 470UF 16V SMD 066607
C28 CAP ELECT 470UF 16V SMD 066607
C29 CAP ELECT 470UF 16V SMD 066607
C30 CAP ELECT 470UF 16V SMD 066607
C31 CAP ELECT 470UF 16V SMD 066607
CONTROL PCB 751898
1
INTERCONNECT
Ref. No. Description Part No.
C32 CAP ELECT 220UF 25V SMD 066606
C33 CAP ELECT 220UF 25V SMD 066606
C34 CAP ELECT 4.7UF 50V SMD 066601
C35 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C36 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C37 CAP ELECT 4.7UF 50V SMD 066601
C38 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C39 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C40 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C41 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C42 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C43 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C44 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C45 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C46 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C47 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C48 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C49 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C50 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C51 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C52 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C53 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C54 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C55 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C56 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C57 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C58 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C59 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C60 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C61 CAP 100pF 200V 5% SMD0805 061390
C62 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C63 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C64 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C65 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C66 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C67 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C68 CAP .01uF 50V 20% X7R SMD0805 061372
C69 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C70 CAP 3300PF 250V UL/CSA 061312
C71 CAP ELECT 3300UF 35V 066509
C73 CAP ELECT 3300UF 35V 066509
C74 CAP ELECT 3300UF 35V 066509
C77 CAP ELECT 3300UF 35V 066509
C78 CAP ELECT 47UF 450V 066560
C80 CAP POLYPROP 0.22UF 400V 20% 064438
C84 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C85 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C86 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C87 CAP MONO .1uF 50V +/-20% X7R SMD 061365
C88 CAP ELECT 100UF 25V SMD 066605
C89 CAP ELECT 220UF 25V SMD 066606
C90 CAP ELECT 220UF 25V SMD 066606
C91 CAP ELECT 100UF 25V SMD 066605
C92 CAP ELECT 220UF 25V SMD 066606
C94 CAP POLYPROP 0.047UF 10% 275VDC 064466
C95 CAP ELECT 10UF 250V 066558
D1 DIODE SCHOTTKY 40V 2A SMD 070210
D2 DIODE SMALL SIGNAL 4148 SMD 070199
CA1 CABLE FFC 18 CONDUCTOR 70MM 171317
CA2 CABLE FFC12 CONDUCTOR 70MM 171318
CA3 CABLE FFC 18 CONDUCTOR 70MM 171317
CA4 CABLE FFC 12 COND 254MM 171233
CA5 CABLE FFC 18 CONDUCTOR 70MM 171317
CA6 CABLE FFC12 CONDUCTOR 70MM 171318
CA7 CABLE FLAT FLEX 8 PIN 1MM 173026
CA8 CABLE FFC 23 COND 127MM 171234
CA9 CABLE FLAT FLEXIBLE 12 COND 171545
CA10 CABLE ASSY TUBE PHONO 173299
CA11 CABLE ASSY TUBE PHONO 173299
CA12 CABLE ASSY TUBE PHONO 173299
CA13 CABLE ASSY TUBE PHONO 173299
CA14 CABLE ASSY 8 CONDUCTOR 9” 173280
CA15 CABLE ASSY AC 173236
CA16 CABLE FLAT FLEX 8 PIN 1MM 173026
CA17 CABLE ASSY RECEPTACLE/GND WIRE 171723
CA18 CABLE FLAT FLEX 8 PIN 1MM 173026
CA19 CABLE FLAT FLEX 8 PIN 1MM 173026
CA20 CABLE FLAT FLEX 8 PIN 1MM 173026
CA21 CABLE FLAT FLEX 12 COND 200MM 171930
MT1 METER 3.5” 70DB 124120
MT2 METER 3.5” 70DB 124120
T1 CONTACT MCINTOSH SERVICE DEPT
J1 AC RECEPTACLE W/LINE FILTER 3A 118033

McIntosh C2600 Specifications

General

Signal to Noise Ratio	100dB
Phono Stage	Yes
Digital USB Input	1
Digital MCT Input	1
Vacuum Tube	Yes
Type	Tube Preamplifier
Frequency Response	20Hz - 20kHz (+0, -0.5dB)
Phono Inputs	1 Moving Magnet 1 Moving Coil
Outputs	3 Total
Output Impedance	100 ohms
Dimensions	17.5" (44.45cm) x 6" (15.24cm) x 18" (45.72cm)
Headphone Output	1/4" High Drive with Headphone Crossfeed Director (HXD®)
